Category: Extended Bag Filters



[+] Larger

Camfil Cam-Flo XLT Bag Filter

[ Bag filters with fine fiber media ]

High strength synthetic media bag filter that maintains efficiency over time. May be used in hostile environments, moisture, turbulence, etc., operational to 2500 cfm.

Description: Multi-pocket, maintained high efficiency filter with synthetic media for commercial applications.
Typical applications: Built-up filter banks, rooftops, split systems, free-standing units, package systems and air handlers.
Efficiency: MERV 11, MERV 13, and MERV 14 and MERV 11-A, MERV 13-A, and MERV 14-A.
Media: Synthetic media in a uniform high loft media blanket with a permeable media support backing.
Maximum recommended final pressure drop: 1.0" w.g. when operated at 500 fpm. System design or energy considerations may dictate alternative changeout point.
Temperature: Maximum continuous operating temperature of 158º F (70° C).
Ratings: UL Class 900.



Spec Sheet
Sizes | Buy


[+] Larger

Camfil City-Flo XL Bag Filter

[ Bag filters with fine fiber media ]

MERV 13 particle capture efficiency and odor control in one extended surface pocket filter. Excellent for office buildings, retail stores, industrial facilities, medical facilties, shopping centers and schools.

Description: Multi-pocket high efficiency filters with tapered pleats and pocket stitching for the removal of particulates and gaseous contaminants.
Typical applications: Built-up filter banks, rooftops, split systems, free-standing units, package systems and air handlers.
Efficiency: MERV 13 per ASHRAE Standard 52.2 and 92% initial removal efficiency on ozone.
Media: Air laid lofted micro-fine glass media with Rapid Adsorption Dynamics carbon embedded within the media.
Recommended final pressure drop: 1.0" w.g. when operated at 500 fpm. System design may dictate alternative change-out point.
Temperature: Maximum continuous operating temperature of 122º F (50° C).



Spec Sheet
Sizes | Buy


[+] Larger

Camfil Hi-Flo Bag Filters

[ Bag filters with fine fiber media ]

Longest lasting pocket style filter available in the industry. Proprietary media, exclusive to Camfil, optimized for the highest dust holding capacity. Controlled Media Spacing (CMS) for longer life.

Description: Multi-pocket high efficiency filters with tapered pleats and pocket stitching.
Typical applications: Built-up filter banks, rooftops, split systems, free-standing units, package systems and air handlers.
Efficiency: MERV 9, MERV 11, MERV 13, MERV 14 and MERV-A of 9, 11, 13, and 14 respectively.
Media: Microfine glass media in a uniform high loft media blanket with a synthetic micro mesh media backing.
Recommended final pressure drop: 1.0" w.g. when operated at 500 fpm. System design may dictate alternative changeout point.
Temperature: Maximum continuous operating temperature of 158º F (70° C).
Ratings: ECI value of five stars, UL Class 2.



Spec Sheet
Sizes | Buy


[+] Larger

Camfil Hi-Flo ES Bag Filters

[ Bag filters with fine fiber media ]

Lowest initial and average pressure drop to ensure the lowest energy cost in the industry. May be used without a pre-filter to further reduce energy costs. Longest lasting pocket style filter available in the industry, less changes and less landfill waste. Proprietary high loft air laid media, exclusive to Camfil, depth optimized for the highest dust holding capacity. Tapered pockets offer Controlled Media Spacing (CMS) for full use of media area. Transport handle built into carton for ease of filter service. Molded plastic frame, no jagged edges, no pocket damage, no air bypass. Guaranteed to 10" w.g. without filter failure.

Description: Multi-pocket high efficiency filters with tapered pleats and pockets available in 12", 22" and 30" depths.
Typical applications: Built-up filter banks, rooftops, split systems, free-standing units, package systems and air handlers.
Efficiency: MERV 11, MERV 13, MERV 14, and MERV 15 and a MERV-A of 11, 13, 14 and 15 respectively, efficiency maintained throughout the life of the filter.
Media: Proprietary microfine glass media in a uniform high loft media blanket with a micro mesh media backing.
Recommended final pressure drop: 1.0" w.g. when operated at 500 fpm. System design may dictate alternative changeout point.
Temperature: Maximum continuous operating temperature of 158º F (70° C).
Ratings: ECI value of five stars, listed as UL 900 by Underwriters Laboratories.



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Multi-Wedge 45 Filter

[ ]

Fiber Bond Multi-Wedge filters are made with a tough, high density polyester media manufactured at Fiber Bond. Resistant to high humidity, oil mists, acids, alkalies and most organic solvents. HEAT SEAL CONSTRUCTION All perimeter edges and internal dividers are permanently welded together. This dielectric process assures a leak proof self-supporting pocket. No needle holes for dirt migration downstream. SELF-SEAL FRONT LOAD DESIGN The positive edge self sealing design is used in conventional front access systems. The overlapping media tightly pressure fits against the holding frame. No by-pass around the filter.



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Dustlok Cube Self Style

[ ]

DUSTLOK​ CUBES w/SPOR-AX​ (MERV 9) - Spor-Ax® Biocide Anti-Microbial
- Unaffected by moisture
- 90% @ 10 microns
- Combines the highest efficiencies​ & dust holding capacities with extremely low restriction
- Easy to handle and dispose of
- Eliminates costly air bypass​
APPLICATIONS - Hospitals or multi stage units as a pre filter to more expensive primary filters
- Colleges/Universities or high rise office buildings as a primary filter
- Any general air application
THE SAVINGS - Highly effective in maintaining clean coils throughout operation resulting in energy conservation
- Reduced labor and material costs
- Eliminates molds and spores
- Enhances indoor air quality
- Reduces IAQ liabilities​



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Dustlok 440 Cube

[ ]

Dustlok 440 Cube
The 440 cube design provides two large tapered pockets for collection of airborne contaminants. Available in a 15 inch depth and a compact 8 inch model when space is a limiting factor.
The 9 gauge internal grid and overlapping media seals the cube tightly into the holding frame.
APPLICATIONS - Hospitals or multi stage units as a pre filter to more expensive primary filters
- Colleges/Universities or high rise office buildings as a primary filter
- Any general air application
THE SAVINGS - Highly effective in maintaining clean coils throughout operation resulting in energy conservation
- Reduced labor and material costs
- Eliminates molds and spores
- Enhances indoor air quality
- Reduces IAQ liabilities​



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Multi-Wedge 65 Filter

[ ]

Fiber Bond Multi-Wedge 65 media is a tough, high density polyester manufactured at Fiber Bond. Resistant to high humidity, oil mists, acids, alkalies and mostorganic solvents. The high dust holding capacity makesthe MW65 'H' a stand alone filter. HEAT SEAL CONSTRUCnON Allperimeteredges andinternaldividers arepermanently welded together. This dielectric process assures aleak proofself-supportingpocket. Noneedleholesfordirt migration downstream. The self-supporting pockets withstand the most severe environmental operating conditions. SPOR-AX -NO EARLY CHANGE OUTS Spor-Ax antimicrobial is a proven, highly effective biocide which controls growth of mold, mildew, algae and fungi on the filter. Mold build up on filter media will increase resistance. No early or unanticipated filter purchases and change outs.



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Multi-Wedge 85 Filter

[ ]

Fiberbond Multi-Wedge 85 ~ Self-Supporting Pockets: pockets stay erect at any airflow, even shut down. No pocket stress. 100% Synthetic Media: non-shedding, non-carcinogenic. Welded Pocket Seals: no dirt leakage, no needle holes Spor-Ax Antimicrobial: controls growth of mold, mildew, algae and fungi on the filter. No premature change out.



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Multi-Wedge 95 Filter

[ ]

Fiberbond Multi-Wedge 95 ~ Self-Supporting Pockets: pockets stay erect at any airflow, even shut down. No pocket stress. 100% Synthetic Media: non-shedding, non-carcinogenic. Welded Pocket Seals: no dirt leakage, no needle holes Spor-Ax Antimicrobial: controls growth of mold, mildew, algae and fungi on the filter. No premature change out.



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Dustlok Cube Self Sealing

[ ]

DUSTLOK​ CUBES w/SPOR-AX​ (MERV 9) - Spor-Ax® Biocide Anti-Microbial
- Unaffected by moisture
- 90% @ 10 microns
- Combines the highest efficiencies​ & dust holding capacities with extremely low restriction
- Easy to handle and dispose of
- Eliminates costly air bypass​
APPLICATIONS - Hospitals or multi stage units as a pre filter to more expensive primary filters
- Colleges/Universities or high rise office buildings as a primary filter
- Any general air application
THE SAVINGS - Highly effective in maintaining clean coils throughout operation resulting in energy conservation
- Reduced labor and material costs
- Eliminates molds and spores
- Enhances indoor air quality
- Reduces IAQ liabilities​



Spec Sheet
Sizes | Buy


[+] Larger

Fiberbond Dustlok 30-HC

[ ]

The 12” deep multi-pocket filter is designed with heat-sealed pocket edges and internal dividing bars. It delivers exceptionally high dust-holding and extended service life.

DUSTLOK​ CUBES w/SPOR-AX​ (MERV 9) - Spor-Ax® Biocide Anti-Microbial
- Unaffected by moisture
- 90% @ 10 microns
- Combines the highest efficiencies​ & dust holding capacities with extremely low restriction
- Easy to handle and dispose of
- Eliminates costly air bypass​


APPLICATIONS - Hospitals or multi stage units as a pre filter to more expensive primary filters
- Colleges/Universities or high rise office buildings as a primary filter
- Any general air application


THE SAVINGS - Highly effective in maintaining clean coils throughout operation resulting in energy conservation
- Reduced labor and material costs
- Eliminates molds and spores
- Enhances indoor air quality
- Reduces IAQ liabilities​



Spec Sheet
Sizes | Buy


[+] Larger

Filtration Group Soniq Bag Filter

[ ]

Filtration Groups Aerostar SoniQ pocket Filter ~ offers high efficiency filtration while maintaining low resistance to airflow. The non-shed media eliminates fiber migration downstream and the ultrasonic welding provides lower resistance with no disruption to the integrity of the filter. The open throat design and the precise pocket spacing produces a product that is aerodynamically balanced and provides excellent all-round performance. ~ the SoniQ Pocket Filters are designed as primary or secondary filters in heating, ventilation and air conditioning systems. Superior dust-holding capacities allow these filters to be used in most commercial and industrial applications as well as hospitals, automotive plants and biotechnology facilities. ~ Certain specialty applications such as oil mist, fume and grease collection require Fiberglass or Class 1 Pocket Filters. SoniQ Pocket Filters can be sued in most standard built-up filter banks or side-access housing systems.



Spec Sheet
Sizes | Buy


[+] Larger

ViskonAire Fiberglass Bag Filters

[ ]

ViskonAire Fiberglass Bags ~ Whether it’s bacteria, mold spores and pollen: or equipment damaging and wall staining dust you have to remove from the air, Viskon-Aire High Efficiency Filters give you three certified efficiencies to choose from. ~ With a low initial pressure drop, and a design that allows the fullest use of media, you save energy, and dollars too. ~ High Efficiency _ A higher practical efficiency is achieved because of longer filter life. Each time filters are changed efficiency is reduced to their clean efficiency. Longer filter life means that filters are operating longer at higher efficiency.



Spec Sheet
Sizes | Buy


[+] Larger

AS-Synthetic Bag Filter

[ ]

Viskon-Aire ~ AS Series ~ These filters provide low initial pressure drop, high dust holding capacity, and a long service life. The “AS” series extended surface filters are ideal for applications requiring an absence of glass micro fibers and economical price. ~ The multiple layered construction of the “AS: series product enhances depth loading to achieve full media utilization and the longest service life possible. The combination of new synthetic technology and established manufacturing techniques used in the “AS” series filter has produced the best value filter on the market. The “AS” series filters are available in 45%, 65%, 85%, and 95% efficiencies. These filters are available in an extensive list of standard sizes as well as special sizes upon request. ~ “AS” series filters are constructed for performance and durability; each pocket is formed with individual pocket spacers and a thermoplastic sealant to ensure leak free construction. Each pocket is adhesive bonded to a corrosion resistant metal frame. With state of the art stitching equipment, very consistent media control stitching is achieved to allow for full media utilization.



Spec Sheet
Sizes | Buy


[+] Larger

Revolution Bag Filter

[ ]

8 pocket Revolution Synthetic Bag Filter



Spec Sheet
Sizes | Buy


[+] Larger

440 Self Sealing & Header Bag Filters

[ ]

Viskon-Aire Series 440 Filters are used in office buildings, hospitals, manufacturing plants and all applications where long life and high efficiency are required. Series 440 Filters are used with or without the optional header frame to replace all types of extended surface filters such as cubes, supported multi-pocket, and pleated filters. ~ The unique filter media and exclusive PBT-32 Tackifier give the Seris 440 Filter tremendous dust holding capacity and considerably greater service life than competitive medium efficiency filters. The self-gasketing feature is designed with the compressed media acting as a gasket so that a force fit against the holding frame will eliminate by-pass. ~ Easy installation: preformed filter fits into existing frames with ease. There is no basket to install or retainer clips to become lost or damaged when the filter must be changed. Filters are packaged with the pockets folded. When installed, the pockets spring open and are self-supporting. Series 440 filters are available in an extensive number of standard sizes as well as special sizes upon request.



Spec Sheet
Sizes | Buy
